DuraPro ASA CF combines ASA's genuine UV and weather resistance with the added stiffness of carbon fiber reinforcement. Carbon fiber content significantly increases rigidity and heat resistance compared to standard ASA, making it well suited to mechanically demanding outdoor and automotive parts. It offers good layer adhesion, low warping, and a matte, technical surface finish. A hardened nozzle is required for printing, due to the abrasive nature of the carbon fiber content.
From the Austrian Alps, every Extrudr spool is manufactured with care, precision and strict EU standards.
From standard FDM printers to AMS and multi-material setups, Extrudr filament is built to work reliably with the printer you already own.
Independently tested for UV and weather resistance, holding its colour and integrity through extended outdoor exposure.
Significantly increases rigidity and mechanical strength, so parts resist flexing and hold their shape under load.
A precise, matte surface finish with a professional, technical look and feel.
Improved thermal performance over the standard blend, holds its shape reliably under serious thermal stress.
DuraPro ASA CF is compatible with all standard FDM printers on the market. Note: an enclosed print space is required, and a heated bed capable of reaching 100–110°C is recommended.
Yes. As with all carbon-fiber-reinforced materials, the abrasive content will gradually wear down a standard brass nozzle. We recommend a hardened nozzle (e.g., hardened steel or ruby) for smooth, reliable extrusion and consistent nozzle lifespan.
Yes. DuraPro ASA CF is fully compatible with AMS (Automatic Material System) solutions, including the Bambu Lab AMS.
Yes. DuraPro ASA CF is a hygroscopic material and should be dried before printing to achieve optimal print quality. We recommend drying for 10 hours at 60°C.
Yes. DuraPro ASA CF retains the UV and weather resistance of standard ASA, making it suitable for outdoor and automotive applications.
DuraPro ASA CF offers greater stiffness and improved heat resistance than standard ASA, thanks to carbon fiber reinforcement. As with all carbon-fiber-reinforced materials, this added rigidity comes with a trade-off in impact resistance compared to standard ASA, making it best suited to applications where stiffness matters more than shock resistance.
No. Carbon fiber reinforced filaments, including DuraPro ASA CF, are not certified for food contact.
DuraPro ASA CF is rated UL 94 HB for flame retardancy.
Compliance applies to the raw material, not the finished printed part. Any part intended for a regulated application must undergo separate certification by an accredited third-party laboratory. Requirements vary depending on intended use and applicable standards.
Store DuraPro ASA CF in a dry room at room temperature (18–27°C / 65–80°F). Stored neatly, it is protected from dust and sunlight.
When stored correctly, DuraPro ASA CF has a shelf life of 2 years.
Recommended settings for printers with a 0.4 mm nozzle. Max. 50% layer height. Optimal settings may vary between printers and are also dependent on environmental factors.
Our material profiles make printing easier and more reliable. The profiles are perfectly optimised for Extrudr filaments and deliver perfect results straight away. Simply select your printer and material, import the profile into your slicer, and you’re ready to go.
| Mechanical Properties | Method | Value | Rating |
|---|---|---|---|
| Tensile modulus (Young's modulus) | ISO 527-1 | 4100 MPa | Excellent |
| Tensile strength at yield | ISO 527-1 | 58 MPa | Very Good |
| Tensile stress at break | ISO 527-1 | 55 MPa | Excellent |
| Elongation at break | ISO 527-1 | 2.5 % | Typical |
| Flexural modulus | ISO 178 | 4000 MPa | Excellent |
| Flexural strength | ISO 178 | 88 MPa | Very Good |
| Charpy notched impact strength (+23°C) | ISO 179-1eA | 7 kJ/m² | Good |
| Charpy notched impact strength (-30°C) | ISO 179-1eA | 5 kJ/m² | Typical |
| Charpy unnotched impact strength (+23°C) | ISO 179-1eU | 25 kJ/m² | Typical |
| Charpy unnotched impact strength (-30°C) | ISO 179-1eU | 18 kJ/m² | Typical |
| Puncture maximum energy (-30°C) | ISO 6603-2 | 4 J | - |
| Multiaxial instrumented impact, peak force (-30°C) | ISO 6603-2 | 1900 N | Typical |
| Thermal Properties | Method | Value | Rating |
|---|---|---|---|
| Heat deflection temp. (HDT/B) — 0.45 MPa | ISO 75-1 | 96 °C | Very Good |
| Heat deflection temp. (HDT/A) — 1.8 MPa | ISO 75-1 | 84 °C | Very Good |
| Vicat softening temp. (VST/B50) | ISO 306 | 97 °C | Very Good |
| Melting point (Tm) | ISO 3146-C | 210–250 °C | - |
| Glass transition temp. (Tg) | ISO 11357-1 (DSC) | 103 °C | Excellent |
| Melt flow rate (MFR) — 210°C/2.16 kg | ISO 1133-1 (210°C/2.16 kg) | 2 g/10 min | Typical |
| Melt volume rate (MVR) — 235°C/5.0 kg | - | 12 cm³/10 min | Very Good |
| Thermal decomposition temp. | - | 350 °C | Excellent |
| CLTE — flow direction | - | 0.55 cm/cm/°C | Excellent |
| Physical Properties | Method | Value | Rating |
|---|---|---|---|
| Density | ISO 1183-1 | 1.13 g/cm³ | - |
| Water absorption (saturation, 23°C) | - | 0.8 % | - |
| Mould shrinkage | ISO 294-4 | 0.3 % | Excellent |
| Special Properties | Method | Value | Rating |
|---|---|---|---|
| Flame retardant rating 1.5mm | - | HB (UL94) | - |
| UV resistance | - | Good | - |
| Chemical resistance | - | Good | - |
| Flame retardant rating 3,0mm | - | HB (UL94) | - |
| Fire & Compliance | Method | Value | Rating |
|---|---|---|---|
| Flammability rating (UL 94) | - | HB (1.5 mm) | - |
